Residential Energy Storage

Perfect for small to medium-sized households looking to maximize their solar investment. Built with advanced LiFePO4 battery technology, it ensures superior safety, long cycle life, and stable performance.

Key Features

Compact & Safe: High-safety LFP chemistry.

Easy Installation: Wall-mount or floor-stand options.

10+ Year Lifespan: Optimized for daily charge/discharge cycles.

5kWh home energy storage system LiFePO4 battery

5kWh LiFePO4 home energy storage system for residential solar applications

residential energy storage battery LiFePO4

5kWh LiFePO4 home energy storage system for residential solar applications

5kWh LiFePO4 home energy storage system for residential solar applications

General Q&A

Q: How long can a 5kWh battery power a home?
A: A 5kWh battery can power essential home appliances for several hours depending on energy consumption.

Q: Is LiFePO4 safe for home use?
A: Yes, LiFePO4 batteries are among the safest lithium battery technologies with high thermal stability.

Q: Does it support remote monitoring?
A: Yes, most StorXing systems support remote monitoring via RS485, CAN, or Bluetooth/WiFi connectivity.

Q: Can I expand the capacity later?
A: Yes, our modular designs allow for easy parallel connection to increase capacity as your energy needs grow.

Parameter

Specification

Battery Type

LiFePO4 (Lithium Iron Phosphate)

Nominal Capacity

5kWh

Nominal Voltage

48V / 51.2V

Cycle Life

≥6000 cycles

Depth of Discharge

≥95%

Charging Voltage

54.6V

Discharge Cut-off Voltage

40V

Max Charge Current

50A

Max Discharge Current

100A

Communication

CAN / RS485

Operating Temperature

-10°C ~ 50°C

Installation

Wall-mounted / Floor-standing

Protection

Smart BMS (Overcharge, Overdischarge, Short Circuit)

Warranty

5–10 Years

Compact 5kWh LiFePO4 battery for residential solar self-consumption. Safe, long-lasting, and ideal for residential use.

Parameter	Specification
Battery Type	LiFePO4 (Lithium Iron Phosphate)
Nominal Capacity	5kWh
Nominal Voltage	48V / 51.2V
Cycle Life	≥6000 cycles
Depth of Discharge	≥95%
Charging Voltage	54.6V
Discharge Cut-off Voltage	40V
Max Charge Current	50A
Max Discharge Current	100A
Communication	CAN / RS485
Operating Temperature	-10°C ~ 50°C
Installation	Wall-mounted / Floor-standing
Protection	Smart BMS (Overcharge, Overdischarge, Short Circuit)
Warranty	5–10 Years
